| Input voltage |
Strobe |
| 100V-240V AC,50/60Hz |
Electronic strobe, 0.3~25 F.P.S |
|
|
| Input power |
Head movement |
| 1450W@220V |
Pan 540º, Tilt 270º with auto position correction and 16 bit control |
| 1600W@100V |
|
|
Control |
| Light sources |
International standard DMX512 signal and RDM function |
| 1000W white LED module,6900K |
38channels in short mode, 42channels in standard mode,57channel in extended mode |
| Ra≥95, R9≥95 ( Optional highly bright version: Ra≥70) |
|
| Manufacturers Rated Lamp Life:>20000hrs |
Control interface |
|
DMX512 ports（5-pin) |
| Cto |
Ethernet port RJ45 |
| Linear CTO system(0-100%, 1800K-6500K) |
|
|
Other functions |
| Effect wheel |
Pan and Tilt speeds adjustable |
| 1 animation effect wheel, bi-directional rotation with varied speeds |
Pan and Tilt swappable and invertible |
|
High precision magnet sensor for positioning |
| Iris |
3.2-inch touch color screen, Chinese and English menus, |
| Linear iris 5-100% with macros |
Screen automatic lock –up while standby |
|
Error diagnostic system with sensors |
| Prism |
Smart fan cooling system |
| 1 pc of 4-facet circular prism, bi-directional rotation with varied speeds with indexing function |
Display of fixture hours and software versions |
|
Modular construction for easy maintenance |
| Frost |
Isolated input signals |
| 1 heavy frost filter (0-100% linear) |
Firmware update via DMX cable or USB port |
|
DMX512 wireless reciever |
| Beam angle |
DMX512 Transmitter(Optional) |
| Linear zoom 6°～ 54° with 16 bit precision |
ArtNet and sACN(Optional) |
|
|
| Focus |
IP Rating |
| Linear focus with auto-focus function |
IP20 |
|
|
| Dimmer |
Operation temperature |
| Linear electronic dimmer 0-100% with 16 bit control |
Ambient temperature 45℃ at maximum |
| 3 dimmer speeds |
|
| 4 dimmer gamma curves |
Weight |
| Dimmer frequency adjustable between 1.2K and 25K |
Net weight 45Kg |
|
|
|
|
|
|
|
|
